Double Sided Slimline Outdoor LCD Display
Our double sided LCD display allows you to capture attention from both directions, simultaneously. This display is perfect for public transport applications. For example, train stations can use this display to display train timetable information. Furthermore, its double sided features make it easy for commuters to read timetable information from anywhere the platform.
Key Features of Metrospec's Double Sided Slimline Outdoor LCD Display
Shine Bright
Our screens come equipped with anti-reflective laminated glass for easy viewing. They also have a brightness of 2,500 Bits and are readable in direct sunlight and in dim or low light. Additionally, its long rectangular shape with sleek, modern casing fits in perfectly within any setting.
Customisable
Our display enclosures are available in different colours to suit your specifications. They also feature a range of audio connectivity options including PC/Media players to suit all users. This display is also fully serviceable in the field. Our double sided outdoor LCD displays also come in a large range of sizes. They range from 19”-55″ and display in landscape or portrait modes. They also measure ⅓ or ½ of a 55″ display in height.
No Dig Coil Perimeter
Due to the inbuilt coil, operators will be pleased to learn that there is no digging required when installing one of these totems as a perimeter for the Hearing Loop System is NOT required to operate.
Built for the Elements
Our double sided outdoor LCD displays are IP65 rated. This means, you can rest easy knowing they are reliable and will last for years to come. This display has been built for the outdoors and can withstand extreme temperatures, rain, snow, dust and corrosion from salty air. They also come with anti-vandalism features to protect the screens and can run 24/7 without burning out. To top things off this display is fully serviceable in the field.
In-Built Voice Annunciator & Hearing Loop
The Voice Annunciator and Digital Hearing Loop System is activated when the illuminated button on the totem is pushed. This button signals the network amplifier controller to read the timetable information displayed on the screen. Those who require hearing assistance and wear hearing aids can tune into the voice annunciator broadcast by activating the “T-Switch” on their hearing device. Delivery of the broadcast is a considerable height range from 1-2 metres with a strong signal and little interference
Software
This display comes with various software options to run content and display information on the screen.
Specifications
Get all the details.
The MetroSpec Double Sided LCD Display is available in a range of sizes. Technical Specifications for the 38” is listed below. Please contact us directly for information on other sizes.
Metrospec's Double Sided Slimline Outdoor LCD Display Specifications
- Sunlight Readable
- Weather Resistant
- Easy to Install and Maintain
- IP65 Enclosure
- Reliable 24/7 Operation
- Inbuilt Voice Annunciator
- Inbuilt Hearing Loop System
- Serviceable in the field
| DOUBLE SIDED SLIMLINE | |
|---|---|
| LCD Panel Size | 38” or 42” ½ Height |
| Resolution | 1920 x 540, 32:9 |
| Brightness | 1500 Nits |
| Contrast Ratio | 1200:1 (typ). |
| Response Time | 8ms (typ). |
| Viewing angle | Viewing angle free R/L 178⁰(Min.) U/D 178⁰ (Min.) |
| Half Light Life Time | 50,000 Hours |
| Active Area | 261.63 (H) x 930.24 (W) mm |
| Power Consumption | 280W |
| STANDARDS | |
|---|---|
| EN55002 - CE - IEC60950 | Standard |
| ENCLOSED MONITOR | |
|---|---|
| Aluminium | Standard |
| Enclosure Colour Black | Standard |
| Other Colours | Option |
| Dimensions | 485 (H) x 1200 (W) x 200 (D) mm |
| Weight | 50kg |
| Front Glass Anti-Reflective/Laminated | Standard |
| Ceiling Droppers | Optional Certified Load Droppers for wind and vibration loads are also available |
| ENVIRONMENTAL | |
|---|---|
| Operating Temperature | -15⁰C to +50⁰C |
| Optional Extended Operative Temperature which includes Intelligent Internal Environmental Control System | -40⁰C to +50⁰C |
| Storage Temperature | -20⁰C to +60⁰C |
| Humidity | 10% to 90% |
| OPTIONS | |
|---|---|
| Other Inputs | Ethernet Wi-Fi; USB; 3G/4G; AUDIO, BUILT IN COMPUTER |
| Video Input Options | DVI; VGA; RGB; Composite; |
| Touch Screens | Near Field Capacitive or Infrared |
| Security & Protection Options | Password Protected Remote Control; Condensation Protection Circuitry; Over/Under Temperature Protection; Intelligent Internal Environmental Control |
| ACCESSORIES | |
|---|---|
| Remote Control / AAA Batteries (2) | Optional |
| Quick Start Guide | Standard |
| VGA Cable | Standard |
| OPTIONAL ACCESSORIES | |
|---|---|
| Wall mount, Side mount, Vesa Mount, Mounting Brackets Available | Optional |
| Bird Deterrents - Rollers or Spikes | Optional |
| Protection Hoods | Optional |
| MetroSpec PID Monitoring System (MPMS) | Optional |
| SOFTWARE | |
|---|---|
| MetroSpec Monitoring Software (NMS) | Optional |
| MetroSpec Presenter Software | Optional |
| 4Tel Real Time Scheduling Software | Optional |
| PADS Software | Optional |
