OUTDOOR LED DISPLAYS
Direct, engage and communicate to audiences with text, animation and clear messaging with an Outdoor LED Display
Learn more
Metrospec Outdoor LED Displays
Efficient, Reliable, Outdoor LED Displays
SCREENS
Brightness from 5000+ Nits; Most models IP65 Front/IP54 Back
LARGE RANGE OF SIZES
Modular – create the size display that you desire
DURABLE
Weather proof and suitable for 24/7 Operation
PRODUCT DETAILS
The MetroSpec range of Outdoor LED Displays are scalable and modular with the DIP or SMD LED Technology encased in a lightweight aluminium housing which simply mounts together to produce a LED Sign to the size that you the customer requires. LED is energy efficient and Ultra Bright with outdoor models having a brightness of more than 5000 nits.
MetroSpec have a range of single and tri colour LED Displays to full colour LED Displays that are capable of animated advertising and live game scores – pixel pitch starts from 5.71 up to 20mm.
Metrospec Outdoor LED Displays
Technology designed to wow and deliver your message
CUSTOMISE
Easy to install with stacking design; Modular – create the size display that you desire
CONVENIENCE
Easy to maintain and serviceable from the front/back; Some models have a high refresh rate for live broadcasting
FLEXIBLE
Different shapes are available such as concave, convex, right angle and straight; Software Options to run your content and display the information to the screen
TECHNICAL SPECIFICATIONS
The MetroSpec Outdoor LED Displays are available in a multitude of sizes, pixel pitch and housing configurations – there is a LED Screen to suit your application. A range of specifications for various models are shown below. Please contact us directly for information on other sizes.
| SERIES MODEL | MFix A10 | MFix A16 | MFix S6 | MFix S8 | MFix S10 |
|---|---|---|---|---|---|
| Pixel Pitch (mm) | 10` | 16 | 6.667 | 8 | 10 |
| Brightness Adjustable (nits) | 6000 | 8000 | 7500 | 7500 | 7000 |
| LED Encapsulation | DIP346 | DIP346 | DIP3535 | DIP3535 | DIP3535 |
| Optimum Viewing Angle | H:120° ; V:60° | H:110° ; V:50° | H:120° ; V:100° | H:120° ; V:100° | H:120° ; V:100° |
| Panel Size (mm) | 960x960 | 1024x1024 | 960x960 | 960x960 | 960x960 |
| Panel Resolution (pixels) | 96x96 | 64x64 | 144x144 | 120x120 | 96x96 |
| Panel Weight (kg) | 54 | 53 | 50 | 50 | 50 |
| Power Consumption (max/Ave) (W/sqm) | 618/206 | 782/267 | 796/265 | 906/302 | 846/282 |
| Refresh Rates (Hz) | 1000 | 1000 | 4000 | 4000 | 4000 |
| Grey Level (bit) | 14 | 14 | 16 | 16 | 16 |
| IP Rating | 65/43 | 65/43 | 65/43 | 65/43 | 65/43 |
| Operating Temperature/Humidity (°C/RH) | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% |
| SERIES MODEL | MSurface6 | MSurface8 | MSurface10 | MSurface16 |
|---|---|---|---|---|
| Pixel Pitch (mm) | 6.6 | 8.3 | 10 | 16.67 |
| Brightness Adjustable (nits) | 5500 | 5500 | 5500 | 5500 |
| LED Encapsulation | SMD3535 | SMD3535 | SMD3535 | SMD3535 |
| Optimum Viewing Angle | H:140° ; V:120° | H:140° ; V:120° | H:140° ; V:120° | H:140° ; V:120° |
| Panel Size (mm) | 800x800 |1200x1200 | 800x800 |1200x1200 | 800x800 |1200x1200 | 800x800 |1200x1200 |
| Panel Resolution (pixels) | 120x120 |180x180 | 96x96|144x144 | 80x80| 120x120 | 48x48| 72x72 |
| Panel Weight (kg) | 14.5|40.5 | 14.5 |40 | 14 |39 | 14|37 |
| Power Consumption (max/Ave) (W/sqm) | 555/185 | 555/185 | 555/185 | 555/185 | 555/185 | 555/185 | 555/185 | 555/185 |
| Refresh Rates (Hz) | >1920 | >1920 | >1920 | >1920 |
| Grey Level (bit) | 14 | 14 | 14 | 14 |
| IP Rating | 65/54 | 65/54 | 65/54 | 65/54 |
| Operating Temperature/Humidity (°C/RH) | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% |
| SERIES | MStorm10 | MStorm 16 | MStorm20 | MStorm25 |
|---|---|---|---|---|
| Pixel Pitch (mm) | 10 | 16.67 | 20 | 25 |
| Brightness Adjustable (nits) | 6500|7500 | 7000|8000 | 7000|8000 | 6500 |
| LED Encapsulation | SMD2121 | SMD2121 | SMD2121 | SMD3528 |
| Optimum Viewing Angle | H:110° ; V:50° | H:110° ; V:50° | H:110° ; V:50° | H:110° ; V:50° |
| Panel Size (mm) | 800x800 |1200x1200 | 800x800 |1200x1200 | 800x800 |1200x1200 | 800x800 |1200x1200 |
| Panel Resolution (pixels) | 80x80 | 120x120 | 48x48 | 72x72 | 40x40| 72x72 | 32x32 |48x48 |
| Panel Weight (kg) | 19.85|46.25 | 19.05 |44.45 | 18.25 |42.65 | 17.85|42.65 |
| Power Consumption (max/Ave) (W/sqm) | 384/128 | 447/149 | 412/63 |481/161 | 412/137| 481/161 | 384/128 |395/131 |
| Refresh Rates (Hz) | >1000 | >1000 | >1000 | >1000 |
| Grey Level (bit) | 14 | 14 | 14 | 14 |
| IP Rating | 65/54 | 65/54 | 65/54 | 65/54 |
| Operating Temperature/Humidity (°C/RH) | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% |
| SERIES MODEL | MPad5.7 | MPad6.7 | MPad8 | MPad10 |
|---|---|---|---|---|
| Pixel Pitch (mm) | 5.71 | 6.67 | 8 | 10 |
| Brightness Adjustable (nits) | 5500 | 6500 | 6500 | 6000 |
| LED Encapsulation | SMD3535 | SMD3535 | SMD3535 | SMD3535 |
| Optimum Viewing Angle | H:120° ; V:100° | H:120° ; V:100° | H:120° ; V:100° | H:120° ; V:100° |
| Panel Size (mm) | 480x480 | 480x480 | 480x480 | 480x480 |
| Panel Resolution (pixels) | 84x84 | 72x72 | 60x60 | 48x48 |
| Panel Weight (kg) | 11.5 | 11.5 | 11.5 | 10.7 |
| Power Consumption (max/Ave) (W/sqm) | 976/326 | 1072/356 | 1063/356 | 1036/336 |
| Refresh Rates (Hz) | >4000 | >4000 | >4000 | >4000 |
| Grey Level (bit) | 16 | 16 | 16 | 16 |
| IP Rating | 65 | 65 | 65 | 65 |
| Operating Temperature/Humidity (°C/RH) | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% | -20~+50/10~90% |
APPLICATIONS
Frequently Asked Questions
What is a module?A module is the basic structure that houses a number of pixels together – it is the smallest element in a LED screen which usually determines the overall size of the display.
What is a cabinet?The cabinet is the frame of the LED sign and this is where all the modules sit either in a standard configuration or custom designed to suit a particular application. Our outdoor cabinets are generally made out of steel or strong aluminium.
What are the available communication methods for outdoor LED displays?Graphics, text and videos can be uploaded by the following methods – cable, Wi-Fi, 3G/4G Mobile. However, we can help you to decide the most suitable communication method depending on our outdoor LED application.
